Water Treatment Equipment : Carbon Filter


CARBON FILTER is designed to remove chlorine, taste, odor and organic matter from water.

Application:

- Remove chlorine and organics as well as particles approx. above 10 microns.
- Improve taste and odor of drinking water and prolongs other industrial process water treatment system operating lifetime.

Capacity:

- Standard design : Our carbon filter flow rate is ranging from 0.1 to 150 m3/hr.
- Made to order : The carbon filter can be built to suit your needs. It is your choice to have automatically / manually operated system or even make your own choice of shell material, type and brand of component etc.
- Media : Selected grade activated carbon

OUR STANDARD CARBON FILTER

Model

Flow rate
(cu.m./hr)

Area Required
LxDxH (m)

Operating W. (tons)




CCF-01

0.1-1.0

1.3x2.1x2.4

0.15

CCF-02

1.0-1.5

1.4x2.2x2.4

0.27

CCF-03

1.5-2.5

1.5x2.3x2.4

0.43

CCF-04

2.5-4.5

1.7x2.5x2.4

0.74

CCF-05

4.5-6.0

1.7x2.5x2.4

0.74

CCF-06

6.0-8.5

1.9x2.7x2.4

1.20

CCF-07

8.5-11.0

2.0x2.8x2.4

1.44

CCF-08

11.0-13.0

2.0x2.8x2.4

1.70

CCF-09

13.0-17.0

2.3x3.1x2.4

2.18

CCF-10

17.0-25.0

2.4x3.2x2.4

2.70

CCF-11

25.0-28.0

2.6x3.4x2.4

3.67

CCF-12

28.0-40.0

2.8x3.6x2.4

4.60

CCF-13

40.0-50.0

3.0x3.8x2.4

5.63

CCF-14

50.0-60.0

3.3x4.3x2.4

7.70

CCF-15

60.0-75.0

3.5x4.5x2.4

8.66

CCF-16

75.0-90.0

3.8x4.8x2.4

11.38

CCF-17

90.0-100.0

4.0x5.0x2.4

13.10

CCF-18

100.0-125.0

4.3x5.3x2.4

15.36

CCF-19

125.0-150.0

4.5x5.5x2.4

18.23
